Temperature Humidity Transmitter Sensor, DC 12 24V RS485 Wall Mounted Duct Type Analog Sensor for Plug in Pipe Measurement

Specification:Item Type: Temperature Humidity Transmitter SensorMaterial: ABSDC Power Supply: 12V‑24V DCMaximum Power Consumption: 0.4WOutput: RS485 OutputResponse Time: Generally Less Than 15 SecondsTemperature Range: ‑40℃ to 80℃ Humidity Range: 0‑100%RHTemperature Resolution: 0.1℃Humidity Resolution: 0.1%RHProduct Length: Approx. 22CM/8.7inGross Weight: 270g/9.5ozPackage List:1 x Temperature and Humidity Transmitter Sensor1 x Accessories1 x Instruction ManualNote:All data are measured manually, and there are certain errors in the measurement results.5.1 Digital devices cannot be connected to the PLC or computer for the following possible reasons:The computer has more than COM port and the port selected is incorrect.The device address is wrong, or there are devices with duplicate addresses (factory default all 1).Wrong baud rate, parity mode, data bits, stop bits.The host polling interval and waiting time for answer are too short, both need to be set 200ms.The 485 bus is disconnected, or the A and B lines are reversed.

• ❤ High Sensitivity Probe: Experience precise temperature and humidity measurements with a high-sensitivity gas detection probe, ensuring stable, accuracy, and a performance.
• ❤ Plug-In Structure: Temperature humidity transmitter sensor features a stainless steel gas tube and flange combination with a plug-in structure. The core detection device ensures professional-grade temperature and humidity sensing.
• ❤ IP67 Design: With a full waterproof shell (IP67), duct type sensor is designed specifically for plug-in pipe temperature and humidity measurement, offering prevent against water, dust, and oil.
• ❤ RS485 Output Mode: Enjoy the welfares of RS485 output mode, providing a wide measurement range, high accuracy, good linearity, and easy installation. Industrial sensor is versatile and suitable for various applications.
• ❤ Four Core Shielded Cable: Equipped with a four-core shielded cable, thermometer hygrometer sensor ensures stable transmission with properties, offering robust anti-interference capabilities.
